Model | KH | ||||||||
Certification | ETL | CE CB ErP | |||||||
Voltage | 110-120V | 220-240V | 220-240V | ||||||
Power | 3.5kW | 6kW | 3.5kW | 5kW | 6kW | ||||
Rated Current | 29.2A | 25A | 16A | 21.7A | 29.5A | ||||
Min. Required Circuit Breaker | 40A | 30A | / | 32A | 40A | ||||
Wire Size | 10#AGW | 2.5mm2 | 4mm2 | ||||||
Min. Water Flow to Activate Unit | 0.25 GPM | 1.5L/min | |||||||
Colors | Blue / Black | ||||||||
Heating Element | Stainless Steel | ||||||||
Water Connection | 1/2" | ||||||||
Control Mode | Electronic Control | ||||||||
Default Working Temp. | 50℃ | ||||||||
Over Heating Protection | 60℃ | ||||||||
Thermal Cut-out | 95℃ | ||||||||
Water Pressure | 0.02-0.6M Pa | ||||||||
Product Size | 198*160*98mm | ||||||||
Gift Box Size | 230*140*230mm | ||||||||
Carton Size (12pcs/CTN) | 710*295*480mm | ||||||||
Loading Quantity | 20'GP: 3000pcs 40'GP: 6000pcs 40'HQ: 6600pcs | ||||||||
Application | Above or under sink / Kitchen / Bathroom/ Cabinet/ Car/ RV/Commercial/ Supermarket/ Hotel/ Flat/ Laundry/ Tubs/ Hospital etc | ||||||||
Feature | 1. High strength ABS splash proof casing 2. Compact size and unlimited supply of hot water 3. Easy installation, can be installed above or under sink 4. Easy touch operation 5. Automatic thermostat 6. Automatic memory function 7. Working indication light and LED digit display for direct temperature setting 8. Multiple protection 9. Built-in pressure relief valve |
