Ip68 Rugged Atex Intrinsically Safe Phone Zone 1 Division 21 Ex Mobile Phone Iecex Android Explosion Proof Mobile Phone
transcend
IP68 Rugged intrinsically safe phone Zone 1 Division ex mobile phone IECEx android 8.1 explosion proof mobile phone for oil/gas
Intrinsically safe smart device is build to meet industry‘s roughest testing standard, fully submit waterproof/drop proof IP68 &Military MIL-STD-810G certification. This design is for protecting people who use in hazardous environments, including oil & gas, mining, munitions ,chemical, pharmaceutical ect.it provide the explosion protection.
| Product Name | Intrinsically safe Smartphone |
| Chipset | MT6763T OctaCore @2.3GHz64bit |
| Operating System | Android 8.1 |
|
Network Band |
LTE FDD B1/2/3/4/5/7/8/12/13/17//20(28A/28B)
LTE TDD B34/B38/B39/B40/B41 |
| LTE service | LTE CAT4/HSPA/TD-SCDMA/1xEV-DO/EDGE/GPRS |
| Memory | 4GB RAM/64GB ROM(Optional 6Gb+128Gb)
Supports up to 128GB with SD card |
| WiFi | IEEE802.11 a/b/g/n/2.4/5.8GHz |
|
SIM Card |
Dual SIM Nano/Micro card,Dual standy |
| Didplay Resolution | 5.7Inch FHD+ 2160*1080 Pixel |
| TP Tourch | IPS/G+FF/Multi touch.support Gloved hand/Wet finger operation |
| BT | BT4.0 with BLE |
| GPS | GPS, GLONASS, BeiDou |
| Senor | G-sensor,ProximitySensor,Gyro/E- compass,
Pressure sensor,heightsensor. |
|
NFC |
13.56mhz |
|
Rear camera |
21MP with flash auto-focusing CMOS |
|
Front camera |
13MP PDAF auto-focusing |
| Speaker |
Size 13*65 box waterproof,dualfront-facing |
|
Mic |
2 Mic solution with noise cancellation |
|
Audio jack |
3.5mm audio jack adaptor |
| Physical Size | 182*85.8*21.2mm |
| Weight |
376g(Inclduing battery) |
| Dedicated Keys | PTT Key, Scan key Programmable Key, Volume
Keys, SOS Red Alert, Power On/Off;Home, Back, & Recent. |
| Battery Capacity | 8000mAh Explosion proof battery |
| Continuous use | 23hours (depending on user environment) |
| Standby: | up to 800hours |
| Certifcaiton | SGS IP68 & Military MIL-STD-810G IP68 waterproof certification |
| atex Certifcaiton | Ex ib IIC T4 Gb IP68(Zone 1) |
| Function | UHF/VHF DMR Radio(Options) |
|
Storage Temperature |
-40 °C ≤ Ta ≤ +70 °C |
|
Working Temperature |
-20 °C ≤ Ta ≤ +60 °C |
Workshop Showing
Q :Are you manufacturer?
A: Yes, we are manufacturers. development centers(R&D center), manufacture center development engineers teams including ID/MD, Software,hardware,Mechanical, project management.Will help clients providing ODM/OEM design, SMT board accessibly, final accessibly.
Q: Would you provide SDK for me?
A: Yes, we offer free SDK if you order sample.In addition, we also have support engineers to assist you with software development.
Q: Does the handheld PDA can support QR code and 2D barcode?
A: Yes, All handle pda device can selct the below 2D barcode scanner, Zebra:SE4710/SE4750SR/SE4750MR/SE4750DP/SE4850,Honeywell:N6603
Q: What is the minimum order(MOQ)?
A: We accept one unit for standard products.
Q: Can we get the sample?
A: Yes, We provide the sample for your testing and product quality qualification.Our engineer will offer the technical support during this
Q: How to order and pay?
A: We accept T/T (bank transfer) payment, AlibabaTrade Assurance,Western Union.
Q: What's Your Products Warranty?
A: We Offer 12 Months Warranty after shipment sent.and Options 24moth extension warranty, the cost will be more 10% up
Q: How long it will take for delivery?
A: Normally,lead time around 3-10days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would be around 5-10 working days. some location maybe a little bit longer.
