Desktop Aluminum Mid Tower Computer Chassis MATX PC Case for Gaming with Big Tempered Glass

Detail Specifications:

1. Motherboard: MATX (Size: 244*244mm),

compatible with DTX(Size: 170*190mm) and ITX  otherboards(Size: 170*170 mm) ,

 *Similar to Z390i motherboard IO vest super frame, water cooling needs thin fan

2. Graphics cardsize 353* 158*66m
The total length and thickness are under the premise that a 25mm thick fan has been installed, supporting within 37mm of the shoulder (more than the height of the full-height IO chip)
*The thickness is calculated based on the PCIE first slot, including the thickness of the back plate and vest

3. Heat dissipation: air-cooled-supports up to 5 fans with a diameter of 120mmand 1 fan with a diameter of 90mm

4. CPU radiator height limit 138mm (from the surface of the CPU)

5. Water cooling: support 240/120 water cooling, cold head within 138mm (recommended size:278*124* 54mm)
* Both air-cooled and water-cooled modes support a 9025 fan at the bottom. This fan can only be installed within 49mm of the motherboard IO vest

6. Power supply: Support ATX large power supply, compatible with SFX-L/SFX small power supply
ATX power supply size is recommended 140*150*86mm. Length over 140mm may interfere with the top 12025 fan and Longer than 170mm will interfere with 280 long graphics cards

7. Hard Disk: Support 2.5-inch hard disk position*2 and 3.5-inch hard disk position*2
2.5 inch hard drive limit height 8mm, and the 3.5-inch hard drive shares the position with the 120 fan on the front panel
